High Precision RV Cycloidal Gearbox 270Nm For Servo Motor

Brand Name : Genius Robotics Zhenkang

Model Number : RV-27C

Certification : CE , ISO9001 , ISO14001

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, L/C

Supply Ability : 5000 / month

Delivery Time : 5-10 Working days

Packaging Details : Carton packing

Customized : Available

Name : RV gearbox

Rated torque : 270 Nm

Reduction gear ratio : 36.57

Contact Now

High Precision RV Cycloidal Industrial Robotics Arm Joint Speed Gearbox Reducer For Servo Motor

RV-27C is a two-stage gear reducer which consists of the 1st stage of planetary gear reducer and the 2nd stage of cycloidal pin-wheel reducer. The first speed reduction is achieved by the meshing between the big gear of center gear and the planetary gear based on the gear reduction ratio. The planet gear is connected to the crank shaft, and the rotation of crank shaft causes the eccentric rotation of the cycloid disc. This achieves the second speed reduction and thus if the crank shaft rotates 360°, the cycloid disc will rotate one tooth in the opposite direction.

Product Features

* With compact structure and high torsional rigidity.
* Low backlash (1’ arcmin).
* Due to the flexible design of inline component, it can save the mounting space.
* RV-E series robot gearbox can support the external load due to the installation of angular contact bearing.
* With a high torque capacity, the rated torque can reach to 500%.
* Small vibration and long service life.

High Precision RV Cycloidal Gearbox 270Nm For Servo Motor

This model high precision RV cycloid reducers are mainly used for medical apparatus and instruments, space, precision positioning turntable, machine tool turret, industrial robot and etc.

High Precision RV Cycloidal Gearbox 270Nm For Servo Motor

High Precision RV Cycloidal Gearbox 270Nm For Servo Motor
